| Parameters | Specification | ||||
| Model | DG | ||||
| Screen Frame Size | 470mm x 370mm~737mm x 737mm | ||||
| Substrate Handling Size (minimum) | 50mm (X) x 50mm (Y) | ||||
| Substrate Handling Size (maximum) |
400mm (X) x340mm (Y) Options:460mm(X)x340mm(Y) 510mm(X)x340mm(Y) |
||||
| Cycle Time | 7s | ||||
| Screen Frame Thickness | 20mm -40mm | ||||
| Substrate Thickness | 0.4mm -6mm | ||||
| Print Pressure | 0kg -20kg | ||||
| Print Speed | 1 -200mm/s | ||||
| Print Gap | 0mm -20mm | ||||
| Substrate Separation |
Speed:0.1-20mm/sec Distance:0mm - 20mm |
||||
| Apply paste option | Solder paste，Printing ink, Silver paste | ||||
The sensor will detect the diameter of solder paste remained under the front squeegee to remind the opreator to supply paste.
It’s controlled by electricity and also capable for supplying the solder paste at fixed times.
Stencil aperture inspection can be programmed to be carried out automatically to detect clogging on stencil opening, eliminate poor printing from the begining.
Attached on CCD Camera XY axis, the dispenser provides basic function of glue dotting using syringe type dispensing needle after solder paste printing.
It will keep the power supply to PC for 10 minutes after power off to protect the production data.
There are 3 options for this function:
① T&H both are controlled.
② Temperature control&Humidity detect.
③ T&H both detect and display.
